500°C Hot Pellet Press

YPH-800CG

Instrument model：YPH-800CG

Pressure limit：0-24T

Piston diameter：95mm

Cylinder stroke：30mm

Intelligent temperature controller temperature range: room temperature -800°C

Intelligent temperature controller temperature control mode: 5 adjustable continuous

temperature control - automatic temperature rise - automatic insulation - natural cooling

Heating range: 500°C

Die size: 100x100mm

Effective space: 80x140mm

Pressure and temperature control accuracy: 0.1T/0.1°C(can be customized to set the accuracy)

Pressure holding time: unlimited time (manual pressure relief)

Display die: 7-inch LCD touch screen/English interface can be switched

Die pressure conversion: PCB control program automatically conversion display sample pressure (Mpa)

Heating plate type: four-column positioning insulation design, upper and lower plate heating

                                upper plate screw suspension design/electroplated polishing panel

Heating core material: Copper heating core

Heat insulation method: imported mica heat insulation board

Cooling method: standard water cooler

Safety configuration: The die temperature exceeds 50 ° C, and the thermostat automatically

                                   prompts "Pay attention to anti-hot".

Power supply: 220V(50Hz/60Hz)/ 110V optional

Equipment power: 1300W

Host size: 245x170x705mm

Temperature controller size: 230x270x180mm

Weight: 70Kg

Configuration description: The size of the control panel can be customized according to

customer requirements, the column can be increased, and the temperature controller can

be optional remote control
